Embedded System

Morse Code
Translator

An Arduino-based communication system that instantly converts text strings into Morse code light signals. Leveraging optimized JSON mapping for flexible character encoding and precise timing control.

C++
Language
JSON
Mapping
UNO
Hardware
Morse Code Translator

Source Code

Complete C++ logic for character mapping and signal generation

#include <ArduinoJson.h>
#define USI unsigned short int
#define USIC USI const

USIC PIN = 13;
USIC SHORT = 700;
USIC LONG = 2000;
USIC BREAK = 100;
const char inputText[] = "bashar";
StaticJsonDocument<1047> doc;
USI runing = 1;

void setup() {
    pinMode(PIN, OUTPUT);
    Serial.begin(9600);
    while (!Serial) continue;

    // JSON Mapping for Morse Code Characters
    const char json[] = "{\"0\":\"----\",\"1\":\".----\",\"2\":\"..---\",...}";
    DeserializationError error = deserializeJson(doc, json);

    if (error) {
        Serial.print(F("deserializeJson() failed: "));
        Serial.println(error.f_str());
        return;
    }
}

void loop() {
    if (runing) {
        Serial.println("Start:");
        USIC inputLen = strlen(inputText);

        for (USI inputIndex = 0; inputIndex < inputLen; inputIndex++) {
            const char currentChar = inputText[inputIndex];
            const char* morse_code = doc[¤tChar];

            // Signal Generation Logic
            USIC morseLen = strlen(morse_code);
            for (USI morseIndex = 0; morseIndex < morseLen; morseIndex++) {
                int morse_part = morse_code[morseIndex];
                digitalWrite(PIN, HIGH);

                if (morse_part == 45) {  // Dash case '-'
                    delay(LONG);
                } else {  // Dot case '.'
                    delay(SHORT);
                }

                digitalWrite(PIN, LOW);
                delay(BREAK);
            }
        }
        digitalWrite(PIN, LOW);
        runing = 0;
    }
}

Key Features

Smart embedded solution design

JSON-Based Mapping

Uses ArduinoJson library to efficiently deserialize and map characters to their Morse code equivalents.

Precise Timing

Accurate control of short (dot), long (dash), and break intervals for standard Morse code complaince.

Visual Output

Direct Hardware abstraction to control onboard LED (Pin 13) for visible signal transmission.

Serial Debugging

Real-time serial console feedback for monitoring current character processing and signal status.

Technology Stack

Hardware and software components

Hardware

Arduino Uno ATmega328P LEDs

Software

C++ Arduino IDE ArduinoJson Library
